Product Thumbnail

Cable Clamp Hanger

35AKL801**

Product Thumbnail

Viatran's easy to use cable clamp/hangers make installations more stable and secure. They can be added after connections have been made by sliding the jaws up to open. Able to support up to 562 lbs. The no crush contoured jaws will not damage the internal breather. These are stock items, try one today!


Request a Quote

Resources



Additional Downloads

Level Product Brochure

Product Selection




Cable Clamp P/N Description   Image

Cable Clamp Hanger Chart

35AKL801XS

Galvanized Cable Clamp Hanger

Cable Clamping Range: .216" - .413" Diameters (5.5 - 10.5 mm)

Average Hook Diameter: .787" (20 mm)

  Galvanized Cable Clamp Hanger 35AKL801XS

35AKL801VA

Stainless Steel Cable Clamp Hanger

Cable Clamping Range: .216" - .413" Diameters (5.5 - 10.5 mm)

Average Hook Diameter: .787" (20 mm)

  Stainless Steel Cable Clamp Hanger 35AKL801VA

Materials

 Housing: Stainless Steel 1.4301 or Galvanized (Zinc)

 Clampin Jaws & Positioning Clips: Fiberglass Reinforced PA



Dimensional Data

 Width: 1.77" (45 mm)

 Height: 6.85" (174 mm)

 Depth: 1.26" (32 mm)

  Cable Clamp Dimensions

Weight   6 oz. (162 g)

Max Tensile Strength  2.5 kN





Cable Clamp Hanger

Product Thumbnail

Cable Clamp Hanger

35AKL801**

Viatran's easy to use cable clamp/hangers make installations more stable and secure. They can be added after connections have been made by sliding the jaws up to open. Able to support up to 562 lbs. The no crush contoured jaws will not damage the internal breather. These are stock items, try one today!


Request a Quote

Cable Clamp Hanger



Cable Clamp P/N Description   Image

Cable Clamp Hanger Chart

35AKL801XS

Galvanized Cable Clamp Hanger

Cable Clamping Range: .216" - .413" Diameters (5.5 - 10.5 mm)

Average Hook Diameter: .787" (20 mm)

  Galvanized Cable Clamp Hanger 35AKL801XS

35AKL801VA

Stainless Steel Cable Clamp Hanger

Cable Clamping Range: .216" - .413" Diameters (5.5 - 10.5 mm)

Average Hook Diameter: .787" (20 mm)

  Stainless Steel Cable Clamp Hanger 35AKL801VA

Materials

 Housing: Stainless Steel 1.4301 or Galvanized (Zinc)

 Clampin Jaws & Positioning Clips: Fiberglass Reinforced PA



Dimensional Data

 Width: 1.77" (45 mm)

 Height: 6.85" (174 mm)

 Depth: 1.26" (32 mm)

  Cable Clamp Dimensions

Weight   6 oz. (162 g)

Max Tensile Strength  2.5 kN




Cable Clamp Hanger

Cable Clamp Hanger
